Biological Microscope XSZ-306A


5 in stock

SKU: MIC-TRI-XSZ-306A Category:


This biological microscope can be much widely used in the research of biology, bacteriology, histology and pathology. It can also be used in school laboratories for teaching.

Fully coated optical system, Mechanical tube length 160 mm
Interpupilary distance 55-75 mm, 360° rotatable
45 mm parfocal and achromatic objectives
Double-layer mechanical stage: stage size 140×155 mm, moving range 50×75 mm
Coaxial coarse and fine focus adjustment: range 30 mm, division of fine focus adjustment 0.002 mm
Focusing stop to prevent objectives & slides from damaging
Rack and pinion adjustment for condenser
Built-in illumination, Adjustable brightness
Power supply 110 V or 220 V, CE approval
A wide range of accessories to be equipped with this multi-purpose microscope

Viewing Head     Compensation-free trinocular head inclined at 30º
Eyepiece              WF10X, P16X (WF16X)
Objective             Achromatic 4X, 10X, 40X(S), 100X (S, Oil)
Stage                    Double-layer mechanical stage, size: 140×160 mm
Condenser           Abbe NA 1.25 condenser with iris diaphragm & filter, rack & pinion adjustment
Focusing              Coaxial coarse & fine focus adjustment
Illumination        Built-in illumination, halogen lamp 6 V/20 W
Package                Each set in Styrofoam put into 1 inner box, 1 inner box filled to 1 carton (42.5×24.5×35.5 cm)
Weight                  15 lb

Additional information

Weight 240 oz
Dimensions 16.5 × 10 × 14.5 in
